MC68302CFC16C

integrated multiprotocol processor,

Rated 5 Rating 5 | reviews | Write a review

Price:: US $8.15~8.15 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 200 :	8.15 / Piece

PartNumber:: MC68302CFC16C

Brand:: Motorola, Inc - Motorola | Pack: QFP | D/C: 97+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-03

From Other Seller

Part Number:MC68302CFC16C
US $8.15 - 8.15
Quantity:

piece

Product Summary

The MC68302CFC16C integrated multiprotocol processor (IMP) is a very large-scale integration (VL-SI) device incorporating the main building blocks needed for the design of a wide variety of controllers. The MC68302CFC16C is especially suitable to applications in the communications industry. The MC68302CFC16C is a high-density complementary metal-oxide semiconductor (HCMOS) device con-sisting of an M68000 microprocessor core, a system integration block (SIB) , and a commu-nications processor (CP) .

Parametrics

MC68302CFC16C absolute maximum ratings: (1) Supply Voltage VDD: -0.3 to +7.0V; (2) Input Voltage Vin: -0.3 to +7.0V; (3) Operating Temperature Range TA: -40 to 85°C; (4) Storage Temperature Range Tstg: -55 to 150°C.

Features

MC68302CFC16C features: (1) On-Chip HCMOS MC68000/MC68008 Core Supporting a 16- or 8-Bit M68000 Family-System; (2) On-Chip 1152-Byte Dual-Port RAM; (3) Bus Arbitration Logic with Low-Interrupt Latency Support System Status and Control Logic; (4) Pulse Code Modulation (PCM) Highway Interface; (5) Nonmultiplexed Serial Interface (NMSI) Implementing Standard Modem Signals; (6) Pulse Code Modulation (PCM) Highway Interface.
