M74HC373M

M74HC373M, high speed octal D-type latche, 7.0 V, 20 mA, 1000 ns, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.11~0.11 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3000 :	0.11 / Piece

PartNumber:: M74HC373M

Brand:: STMicroelectronics - ST | Pack: SOP | D/C: 97+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-07

From Other Seller

Part Number:M74HC373M
US $0.11 - 0.11
Quantity:

piece

Product Summary

The M74HC373M is a high speed octal D-type latche. The M74HC373M utilize advanced silicon-gate CMOS technology. The M74HC373M possess the high noise immunity and low power consumption of standard CMOS integrated circuits, as well as the ability to drive 15 LS-TTL loads. Due to the large output drive capability and the 3-STATE feature, the M74HC373M is ideally suited for interfacing with bus lines in a bus organized system.

Parametrics

M74HC373M absolute maximum ratings: (1)Supply Voltage (VCC): -0.5 to +7.0V; (2)DC Input Voltage (VIN): -1.5 to VCC +1.5V; (3)DC Output Voltage (VOUT): -0.5 to VCC +0.5V; (4)Clamp Diode Current (IIK, IOK): ±20 mA; (5)DC Output Current, per pin (IOUT): ±35 mA; (6)DC VCC or GND Current, per pin (ICC): ±70 mA; (7)Storage Temperature Range (TSTG): -65°C to +150°C; (8)Power Dissipation (PD)(Note 3): 600 mW; (9)Power Dissipation (PD)S.O. Package only: 500 mW; (10)Lead Temperature (TL)(Soldering 10 seconds): 260°C.

Features

M74HC373M features: (1)Typical propagatiodelay: 18 ns; (2)Wide operating voltage range: 2 to 6 volts; (3)Low input current: 1 mA maximum; (4)Low quiescent current: 80 mA maximum (74 Series); (5)Output drive capability: 15 LS-TTL loads.
