PIC16F676T-I/SL

PIC16F676T-I/SL, 13-bit program counter, 250 mA, 6.5V, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.00 / Piece

PartNumber:: PIC16F676T-I/SL

Brand:: Microsoft - Microsoft | Pack: SOP | D/C: 08+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-24

From Other Seller

Part Number:PIC16F676T-I/SL
US $1.00 - 1.00
Quantity:

piece

Product Summary

The PIC16F676T-I/SL has a 13-bit program counter capable of addressing an 8K x 14 program memory space. Only the first 1K x 14 (0000h-03FFh) for the PIC16F676T-I/SL is physically implemented. Accessing a location above these boundaries will cause a wrap around within the first 1K x 14 space.

Parametrics

PIC16F676T-I/SL absolute maximum ratings: (1)Ambient temperature under bias: -40 to +125°C; (2)Storage temperature : -65°C to +150°C; (3)Voltage on VDD with respect to VSS : -0.3 to +6.5V; (4)Voltage on MCLR with respect to Vss : -0.3 to +13.5V; (5)Voltage on all other pins with respect to VSS : -0.3V to (VDD + 0.3V); (6)Total power dissipation(1): 800 mW; (7)Maximum current out of VSS pin : 300 mA; (8)Maximum current into VDD pin : 250 mA; (9)Input clamp current, IIK (VI < 0 or VI > VDD): ± 20 mA; (10)Output clamp current, IOK (Vo < 0 or Vo >VDD): ± 20 mA; (11)Maximum output current sunk by any I/O pin: 25 mA; (12)Maximum output current sourced by any I/O pin : 25 mA; (13)Maximum current sunk by PORTA and PORTC (combined): 200 mA; (14)Maximum current sourced PORTA and PORTC (combined): 200 mA.

Features

PIC16F676T-I/SL features: (1)Power-Saving Sleep mode; (2)Wide Operating Voltage Range – 2.0V to 5.5V; (3)Industrial and Extended Temperature Range; (4)Low-Power Power-on Reset (POR); (5)Power-up Timer (PWRT)and Oscillator Start-up Timer (OST); (6)Brown-out Detect (BOD); (7)Watchdog Timer (WDT)with Independent Oscillator for Reliable Operation; (8)Multiplexed MCLR/Input-pin; (9)Interrupt-on-Pin Change; (10)Individual Programmable Weak Pull-ups; (11)12 I/O Pins with Individual Direction Control; (12)High Current Sink/Source for Direct LED Drive; (13)Interrupt Capability; (14)8-level Deep Hardware Stack; (15)Direct, Indirect, and Relative Addressing modes.
