AT90S1200-12PC

AT90S1200-12PC, 8-bit microcontroller, 13.0V, 40.0 mA, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.00 / Piece

PartNumber:: AT90S1200-12PC

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 09+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-24

From Other Seller

Part Number:AT90S1200-12PC
US $1.00 - 1.00
Quantity:

piece

Product Summary

The AT90S1200-12PC is a low-power CMOS 8-bit microcontroller based on the AVR RISC architecture. By executing powerful instructions in a single clock cycle, the AT90S1200-12PC achieves throughputs approaching 1 MIPS per MHz allowing the system designer to optimize power consumption versus processing speed. The AVR core of the AT90S1200-12PC combines a rich instruction set with the 32 general purpose working registers. All the 32 registers are directly connected to the Arithmetic Logic Unit (ALU), allowing two independent registers to be accessed in one single instruction executed in one clock cycle. The resulting architecture of the AT90S1200-12PC is more code efficient while achieving throughputs up to ten times faster than conventional CISC microcontrollers.

Parametrics

AT90S1200-12PC absolute maximum ratings: (1)Operating Temperature: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)Voltage on Any Pin Except RESET with Respect to Ground: -1.0V to VCC+0.5V; (4)Voltage on RESET with Respect to Ground: -1.0V to +13.0V; (5)Maximum Operating Voltage: 6.6V; (6)DC Current per I/O Pin: 40.0 mA; (7)DC Current VCC and GND Pins: 200.0 mA.

Features

AT90S1200-12PC features: (1)AVR - High Performance and Low Power RISC Architecture; (2)89 Powerful Instructions - Most Single Clock Cycle Execution; (3)1K bytes of In-System Reprogrammable Flash: SPI Serial Interface for Program Downloading, Endurance: 1,000 Write/Erase Cycles; (4)64 bytes EEPROM: Endurance: 100,000 Write/Erase Cycles; (5)128 bytes Internal RAM; (6)32 x 8 General Purpose Working Registers.
