FDS6694

N-Channel MOSFET, 30 V, 12 A, 2.5W, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.41~0.41 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2500 :	0.41 / Piece

PartNumber:: FDS6694

Brand:: Fairchild Semiconductor - Fairchild | Pack: SOP | D/C: 03+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-08

From Other Seller

Part Number:FDS6694
US $0.41 - 0.41
Quantity:

piece

Product Summary

The fds6694 N-Channel MOSFET has been designed specifically to improve the overall efficiency of DC/DC converters using either synchronous or conventional switching PWM controllers. The fds6694 has been optimized for low gate charge, low RDS(ON) and fast switching speed. Applications are (1)DC/DC converter; (2)Power management; (3)Load switch.

Parametrics

fds6694 absolute maximum ratings: (1)VDSS Drain-Source Voltage: 30 V; (2)VGSS Gate-Source Voltage: ±16 V; (3)ID Drain Current – Continuous: 12 A; (4)Power Dissipation for Single Operation: 2.5W; (5)TJ, TSTG Operating and Storage Junction Temperature Range: –55 to +175 °C.

Features

fds6694 features: (1)12 A, 30 V. RDS(ON)= 11 mW @ VGS = 10 V RDS(ON)= 13.5 mW @ VGS = 4.5 V; (2)Low gate charge (13 nC typical); (3)High performance trench technology for extremely low RDS(ON); (4)High power and current handling capability.
