ADM811TARTZ-REEL7

adm811tartz-reel7, reliable voltage monitoring device, -0.3 V to +6 V, 20 mA, SOT, Analog Devices

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.41~0.41 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3000 :	0.41 / Piece

PartNumber:: ADM811TARTZ-REEL7

Brand:: Analog Devices - AD | Pack: | D/C: 05+

Availability:: Supply Ability: 3000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-10-12

From Other Seller

Part Number:ADM811TARTZ-REEL7
US $0.41 - 0.41
Quantity:

piece

Product Summary

The adm811tartz-reel7 is a reliable voltage monitoring device. The adm811tartz-reel7 is suitable for use in most voltage monitoring applications. The adm811tartz-reel7 is designed to monitor six different voltages, each allowing a 5% or 10% degradation of standard PSU voltages before a reset occurs. These voltages of the adm811tartz-reel7 have been selected for the effective monitoring of 2.5 V, 3 V, 3.3 V, and 5 V supply voltage levels. The applications of the adm811tartz-reel7 include Microprocessor systems, Controllers, Intelligent instruments, Automotive systems, Safety systems, Portable instruments.

Parametrics

adm811tartz-reel7 absolute maximum ratings: (1)Terminal Voltage (With Respect to Ground), VCC: -0.3 V to +6 V; (2)Input Current, VCC: 20 mA; (3)Output Current, RESET: 20 mA; (4)Power Dissipation, RA-4 (SOT-143): 200 mW; (5)Derate by 4 mW/℃ Above 70 ℃ θJA Thermal Impedance: 330 ℃/W; (6)Operating Temperature Range: -40 to +85 ℃; (7)Storage Temperature Range: -65 to +160 ℃; (8)Lead Temperature (Soldering, 10 sec): 300 ℃; (9)ESD Rating: 3 kV.

Features

adm811tartz-reel7 features: (1)Superior upgrade for MAX811/MAX812; (2)Specified over temperature; (3)Low power consumption: 5 μA typical; (4)Precision voltage monitor: 2.5 V, 3 V, 3.3 V, 5 V options; (5)Reset assertion down to 1 VCC; (6)Power-on reset: 140 ms minimum; (7)Logic low RESET output; (8)Logic high RESET output; (9)Built-in manual reset.
