ADP1111ARZ-5

ADP1111ARZ-5, step-up/step-down switching regulator, 36 V, 1.5 A, 500 mW, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.80~1.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.80 / Piece

PartNumber:: ADP1111ARZ-5

Brand:: Analog Devices Inc - ADI | Pack: SOP | D/C: 09+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-24

From Other Seller

Part Number:ADP1111ARZ-5
US $1.80 - 1.80
Quantity:

piece

Product Summary

The ADP1111ARZ-5 is a step-up/step-down switching regulator that operates from an input voltage supply of 2 V to 12 V in step-up mode and up to 30 V in step-down mode. The ADP1111ARZ-5 can be programmed to operate in step-up/stepdown or inverting applications with only 3 external components. Applications are (1)3 V to 5 V, 5 V to 12 V Step-Up Converters; (2)9 V to 5 V, 12 V to 5 V Step-Down Converters; (3)Laptop and Palmtop Computers; (4)Cellular Telephones; (5)Flash Memory VPP Generators; (6)Remote Controls; (7)Peripherals and Add-On Cards; (8)Battery Backup Supplies; (9)Uninterruptible Supplies; (10)Portable Instruments.

Parametrics

ADP1111ARZ-5 absolute maximum ratings: (1)Supply Voltage: 36 V; (2)SW1 Pin Voltage: 50 V; (3)SW2 Pin Voltage: –0.5 V to VIN; (4)Feedback Pin Voltage: 5.5 V; (5)Switch Current: 1.5 A; (6)Maximum Power Dissipation: 500 mW; (7)Operating Temperature Range: 0°C to +70°C; (8)Storage Temperature Range: –65°C to 150°C; (9)Lead Temperature (Soldering, 10 sec): 300°C.

Features

ADP1111ARZ-5 features: (1)Operates from 2 V to 30 V Input Voltage Range; (2)72 kHz Frequency Operation; (3)Utilizes Surface Mount Inductors; (4)Very Few External Components Required; (5)Operates in Step-Up/Step-Down or Inverting Mode; (6)Low Battery Detector; (7)User Adjustable Current Limit; (8)Internal 1 A Power Switch; (9)Fixed or Adjustable Output Voltage; (10)8-Pin DIP or SO-8 Package.
