Product Summary

The 74AHCU04D is a general purpose hex inverter. Each of the six inverters is a single stage. The 74AHCU04D is high-speed Si-gate CMOS devices and is pin compatible with low power Schottky TTL (LSTTL). It is specified in compliance with JEDEC standard No. 7A.

Parametrics

74AHCU04D absolute maximum ratings: (1)DC supply voltage: -0.5 +7.0 V; (2)Input voltage range: -0.5 +7.0 V; (3)DC input diode current: -20 mA; (4)DC output diode current: ±20 mA; (5)DC output source or sink current: ±25 mA; (6)DC VCC or GND current: ±75 mA; (7)Storage temperature range: -65 +150 °C; (8)Power dissipation per package: 500 mW.

Features

74AHCU04D features: (1)ESD protection: HBM EIA/JESD22-A114-A exceeds 2000 V; (2)ESD protection: MM EIA/JESD22-A115-A exceeds 200 V; (3)ESD protection: CDM EIA/JESD22-C101 exceeds 1000 V; (4)Balanced propagation delays; (5)All inputs have Schmitt-trigger actions; (6)Inputs accepts voltages higher than VCC; (7)Specified from -40 to +85 and +125 °C.
