MBRS340T3G

mbrs340t3g, Surface Mount Schottky Power Rectifier, 40V, 80A, 3B, DO

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.08~0.08 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2500 :	0.08 / Piece

PartNumber:: MBRS340T3G

Brand:: ON Semiconductor - ON | D/C: 08+

Availability:: Supply Ability: 2500/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-25

From Other Seller

Part Number:MBRS340T3G
US $0.08 - 0.08
Quantity:

piece

Product Summary

The mbrs340t3g is a Surface Mount Schottky Power Rectifier. The mbrs340t3g employs the Schottky Barrier principle in a large area metal-to-silicon power diode. State-of-the-art geometry features epitaxial construction with oxide passivation and metal overlay contact. The mbrs340t3g is suited for low voltage, high frequency rectification, or as free wheeling and polarity protection diodes, in surface mount applications where compact size and weight are critical to the system.

Parametrics

mbrs340t3g absolute maximum ratings: (1)Peak Repetitive Reverse Voltage: 40V; (2)Working Peak Reverse Voltage: 40V ; (3)DC Blocking Voltage: 40V; (4)Average Rectified Forward Current IF(AV) 3.0A @ TL = 110℃; 4.0A @ TL = 105℃; (5)Nonrepetitive Peak Surge Current (Surge applied at rated load conditions halfwave, single phase, 60 Hz): 80A; (6)Operating Junction Temperature TJ: -65 to +150℃; (7)ESD Ratings: Machine Model = C: ＞400V; (8)ESD Ratings: Human Body Model = 3B: ＞8000V.

Features

mbrs340t3g features: (1)Small Compact Surface Mountable Package with J-Bend Leads; (2)Rectangular Package for Automated Handling; (3)Highly Stable Oxide Passivated Junction; (4)Very Low Forward Voltage Drop (0.5 V Max @ 3.0 A, TJ = 25℃); (5)Excellent Ability to Withstand Reverse Avalanche Energy Transients; (6)Guard-Ring for Stress Protection; (7)Device Passes ISO 7637 Pulse #1; (8)Pb-Free Packages are Available.
