TL331IDBVR

tl331idbvr, single voltage comparator, 36 V, 20 mA, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.15~0.15 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3000 :	0.15 / Piece

PartNumber:: TL331IDBVR

Brand:: Texas Instruments - TI | Pack: | D/C: 06+

Availability:: Supply Ability: 3000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-12

From Other Seller

Part Number:TL331IDBVR
US $0.15 - 0.15
Quantity:

piece

Product Summary

The tl331idbvr is a single voltage comparator. It is designed to operate from a single power supply over a wide range of voltages. Operation from dual supplies also is possible if the difference between the two supplies is 2 V to 36 V and VCC is at least 1.5 V more positive than the input common-mode voltage. Current drain is independent of the supply voltage. The output can be connected to other open-collector outputs to achieve wired-AND relationships.

Parametrics

tl331idbvr absolute maximum ratings: (1)Supply voltage, VCC (see Note 1): 36 V; (2)Differential input voltage, VID (see Note 2): ±36 V; (3)Input voltage range, VI (either input): -0.3 V to 36 V; (4)Output voltage, VO: 36 V; (5)Output current, IO: 20 mA; (6)Duration of output short-circuit to ground (see Note 3): Unlimited; (7)Package thermal impedance, θJA (see Notes 4 and 5): 206°C/W; (8)Operating virtual junction temperature, TJ : 150°C; (9)Storage temperature range, Tstg: -65°C to 150°C.

Features

tl331idbvr features: (1)Single Supply or Dual Supplies; (2)Wide Range of Supply Voltage: 2 V to 36 V; (3)Low Supply-Current Drain Independent of Supply Voltage: 0.4 mA Typ; (4)Low Input Bias Current: 25 nA Typ; (5)Low Input Offset Voltage: 2 mV Typ; (6)Common-Mode Input Voltage Range Includes Ground; (7)Differential Input Voltage Range Equal to Maximum-Rated Supply Voltage: ±36 V; (8)Low Output Saturation Voltage; (9)Output Compatible With TTL, MOS, and CMOS.
