TC7SET32FU

TC7SET32FU, CMOS digital integrated circuit, 7.0 V, 20 mA, 200 mW, BGA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.07~0.07 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3000 :	0.07 / Piece

PartNumber:: TC7SET32FU

Brand:: Toshiba Semiconductor - Toshiba | Pack: BGA | D/C: 09+

Availability:: Supply Ability: 3000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-22

From Other Seller

Part Number:TC7SET32FU
US $0.07 - 0.07
Quantity:

piece

Product Summary

The TC7SET32FU is a CMOS digital integrated circuit.

Parametrics

TC7SET32FU absolute maximum ratings: (1)Supply voltage VCC: -0.5 to 7.0 V; (2)DC input voltage VIN: -0.5 to 7.0 V; (3)DC output voltage VOUT: -0.5 to VCC + 0.5 V; (4)Input diode current IIK: -20 mA; (5)Output diode current IOK: ±20 (Note 1)mA; (6)DC output current IOUT: ±25 mA; (7)DC VCC/ground current ICC: ±50 mA; (8)Power dissipation PD: 200 mW; (9)Storage temperature Tstg: -65 to 150 °C; (10)Lead temperature (10 s)TL: 260 °C.

Features

TC7SET32FU features: (1)High speed: tpd = 4.2 ns (typ.)at VCC = 5 V, CL = 15pF; (2)Low power dissipation : ICC = 2 μA (max)at Ta = 25°C; (3)Compatible with TTL outputs : VIL=0.8V (max); VIH=2.0V (min); (4)5.5-V tolerant ll inputs.; (5)Balanced propagation Delays : tpLH≒tpHL.
