Product Summary
The opa2348aidcnr is a single supply, low-power, CMOS op amp in micro packaging. Featuring an extended bandwidth of 1MHz, and a supply current of 45μA, the opa2348aidcnr is useful for low-power applications on single supplies of 2.1V to 5.5V. Low supply current of 45μA, and an input bias current of 0.5pA, make the opa2348aidcnr an optimal candidate for low-power, high-impedance applications such as smoke detectors and other sensors. The opa2348aidcnr is available in the miniature SC70-5, SOT23-5 and SO-8 packages.
Parametrics
opa2348aidcnr absolute maximum ratings: (1)Supply voltage, V- to V+: 7.5V; (2)Signal input terminal, Voltage: -0.5 to +0.5V; current: 10mA; (3)Output short-circuit: continuous; (4)Operating temperature: -65 to +150℃; (5)Storage temperature: -65 to +150℃; (6)Junction temperature: 150℃; (7)Lead temperature: 300℃.
Features
opa2348aidcnr features: (1)Low IQ: 45μA typical; (2)Low cost; (3)Rail-to-rail input and output; (4)Single supply: +2.1V to +5.5V; (5)Input bias current: 0.5pA; (6)Microsize packages: SC70-5, SOT23-8 and TSSOP-14; (7)High speed: power with bandwidth: 1MHz.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
OPA2348AIDCNR |
Texas Instruments |
Operational Amplifiers - Op Amps 1MHz 45uA RRIO Dual Op Amp |
Data Sheet |
|
|
|||||||||||||
OPA2348AIDCNRG4 |
Texas Instruments |
Operational Amplifiers - Op Amps 1MHz 45uA RRIO Dual Op Amp |
Data Sheet |
|
|
