Product Summary
The MC144111DW is a low-cost 6-bit D/A converters with serial interface ports to provide communication with CMOS microprocessors and microcomputers. The MC144111DW contains four converters.
Parametrics
MC144111DW absolute maximum ratings: DC Supply Voltage VDD: -0.5 to +18V; (2) Input Voltage, All Inputs Vin: -0.5 to VDD +0.5V; (3) DC Input Current, per Pin I: ±10mA; (4) Power Dissipation (Per Output) POH: 50mW (TA= 70°C) ; (5) Power Dissipation (Per Package) : 150mW (TA= 70°C); (6) Storage Temperature Range Tstg: -65 to +150°C.
Features
MC144111DW features: (1) Direct R(R)C2R Network Output; (2) Buffered Emitter(R)CFollower Output; (3) Serial Data Input; (4) Digital Data Output Facilitates Cascading; (5) Direct Interface to CMOS μp; (6) Wide Operating Voltage Range: 4.5 to 15 V; (7) Wide Operating Temperature Range: T = 0 to 85°C; (8) Software Information is Contained in Document M68HC11RM/AD.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 MC144111DW |
|
IC QUAD SERIAL D/A CONV 16-SOIC |
Data Sheet |
Negotiable |
|
||||
|
MC144111DWR2 |
|
IC QUAD SERIAL D/A CONV 16-SOIC |
Data Sheet |
Negotiable |
|
||||
