Product Summary

The mb15e05pfv is an input Phase Locked Loop (PLL) frequency synthesizer with a 2.0 GHz prescaler. A 64/65 or a 128/129 can be selected for the prescaler that enables pulse swallow operation. The latest BiCMOS process technology is used, resuItantly a supply current is limited as low as 4.0 mA typ. The mb15e05pfv operates with a supply voltage of 3.0 V (typ.) Furthermore, a super charger circuit is included to get a fast tuning as well as low noise performance. As a result of this, mb15e05pfv is ideally suitable for digital mobile communications, such as DCS 1800 and PCS 1900.

Parametrics

mb15e05pfv absolute maximum ratings: (1)Power supply voltage VCC: –0.5 to +4.0 V; (2)Input voltage VI –0.5 to VCC +0.5 V; (3)Output voltage VO –0.5 to VCC +0.5 V; (4)Output current IO: –10 to +10 mA Except Do output; (5)Ido: –25 to +25 mA Do output; (6)Open drain voltage VooP: –0.5 to 7.0 V; (7)Storage temperature Tstg: –55 +125 °C.

Features

mb15e05pfv features: (1)High frequency operation: 2.0 GHz max.; (2)Low power supply voltage: VCC = 2.7 to 3.6 V; (3)Very Low power supply current : ICC = 4.0 mA typ. (VCC = 3 V); (4)Power saving function : IPS = 0.1 mA typ.(VCC = 3 V); (5)Pulse swallow function: 64/65 or 128/129; (6)Serial input 14-bit programmable reference divider: R = 5 to 16,383; (7)On–chip high performance charge pump circuit and phase comparator, achieving high–speed lock–up and low phase noise; (8)Wide operating temperature: Ta = –40 to 85 °C; (9)Plastic 16-pin SSOP package (FPT-16P-M05)and 16-pin BCC package (LCC-16P-M02).

Diagrams

mb15e05pfv pin connection
