MAX2830ETM+T

RF transceiver, BGA, -0.3V to +4.5V, 10s, max2830etm+t

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.81~4.81 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2500 :	4.81 / Piece

PartNumber:: MAX2830ETM+T

Brand:: Dallas Semiconductor - Maxim | Pack: BGA | D/C: 03+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-02

From Other Seller

Part Number:MAX2830ETM+T
US $4.81 - 4.81
Quantity:

piece

Product Summary

The max2830etm+t is a direct conversion, zero-IF, RF transceiver is designed specifically for 2.4GHz to 2.5GHz 802.11g/b WLAN applications. The max2830etm+t completely integrates all circuitry required to implement the RF transceiver function, providing an RF power amplifier (PA), an Rx/T and antenna diversity switch, RF-to-baseband receive path, baseband-to-RF transmit path, voltage-controlled oscillator (VCO), frequency synthesizer, crystal oscillator, and baseband/control interface. The applications of the max2830etm+t are (1)Wi-Fi, PDA, VOIP, and Cellular Handsets; (2)Wireless Speakers and Headphones; (3)General 2.4GHz ISM Radios.

Parametrics

max2830etm+t absolute maximum ratings: (1)VCCTXPA, VCCPA, and ANT__ to GND: -0.3V to +4.5V; (2)VCCLNA, VCCTXMX, VCCPLL, VCCCP, VCCXTAL, VCCVCO, VCCRXVGA, VCCRXFL, and VCCRXMX_ to GND: -0.3V to +3.9V; (3)B6, B7, B3, B2, SHDN, B5, CS, SCLK, DIN, B1, TUNE, B4, ANTSEL, TXBBI_, TXBBQ_, RXHP, RXTX, RXBBI_, RXBBQ_, RSSI, BYPASS, CPOUT, LD, CLOCKOUT, XTAL, CTUNE to GND: -0.3V to (Operating VCC + 0.3V); (4)RXBBI_, RXBBQ_, RSSI, BYPASS, CPOUT, LD, CLOCKOUT Short-Circuit Duration: 10s; (5)RF Input Power: +10dBm; (6)Continuous Power Dissipation: 2.22W; (7)Operating Temperature Range: -40°C to +85°C; (8)Junction Temperature: +150°C; (9)Storage Temperature Range: -65°C to +160°C; (10)Lead Temperature (soldering, 10s): +260°C.

Features

max2830etm+t features: (1)Transceiver Operates from +2.7V to +3.6V; (2)PA Operates from +2.7V to +4.2V; (3)Low-Power Shutdown Mode; (4)Small 48-Pin Thin QFN Package.
