LTC3772ETS8

LTC3772ETS8, step-down DC/DC controller, 10 V, 1 A, 40 μA, 550 kHz, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.79~1.79 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	1.79 / Piece

PartNumber:: LTC3772ETS8

Brand:: LT Electronics Co., Ltd. - LT | Pack: SOP | D/C: 04+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-10

From Other Seller

Part Number:LTC3772ETS8
US $1.79 - 1.79
Quantity:

piece

Product Summary

The LTC3772ETS8 is a constant frequency current mode step-down DC/DC controller in a low profile 8-lead SOT-23 (ThinSOTTM) and a 3mm × 2mm DFN package. The No RSENSE TM architecture eliminates the need for a current sense resistor, improving efficiency and saving board space. Applications are (1)1- or 2-Cell Li-Ion Battery-Powered Applications; (2)Wireless Devices; (3)Portable Computers; (4)Distributed Power Systems.

Parametrics

LTC3772ETS8 absolute maximum ratings: (1)Input Supply Voltage (VIN): –0.3V to 10V; (2)IPRG, PGATE Voltages: – 0.3V to (VIN + 0.3V); (3)VFB, ITH/RUN Voltages: – 0.3V to 2.4V; (4)SW Voltage: – 2V to (VIN + 1V)or 10V Maximum; (5)PGATE Peak Output Current (<10μs): 1A; (6)Operating Temperature Range (Note 2): – 40°C to 85°C; (7)Junction Temperature (Note 3): 125°C; (8)Storage Temperature Range: –65°C to 125°C; (9)Lead Temperature (Soldering, 10 sec)TSOT-23: 300°C.

Features

LTC3772ETS8 features: (1)No Current Sense Resistor Required; (2)40μA No-Load Quiescent Current; (3)High Output Currents Easily Achieved; (4)Internal Soft-Start Ramps VOUT; (5)Wide VIN Range: 2.75V to 9.8V; (6)Low Dropout: 100% Duty Cycle; (7)Constant Frequency 550kHz Operation; (8)Low Ripple Burst Mode Operation at Light Load; (9)Output Voltage as Low as 0.8V; (10)±1.5% Voltage Reference Accuracy; (11)Current Mode Operation for Excellent Line and Load Transient Response; (12)Only 8μA Supply Current in Shutdown; (13)Low Profile 8-Lead SOT-23 (1mm)and (3mm × 2mm)DFN (0.75mm)Packages.
