LP339MX

lp339mx, Ultra-Low Power Quad Comparator, 570mW, 50mA, NSC, Inc.

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.33~0.33 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 80 :	0.33 / Piece

PartNumber:: LP339MX

Brand:: NSC, Inc. - NSC | Pack: | D/C: 05+

Availability:: Supply Ability: 80/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-09-24

From Other Seller

Part Number:LP339MX
US $0.33 - 0.33
Quantity:

piece

Product Summary

The lp339mx is an Ultra-Low Power Quad Comparator. The lp339mx consists of four independent voltage comparators designed specifically to operate from a single power supply and draw typically 60 μA of power supply drain current over a wide range of power supply voltages. Operation from split supplies is also possible and the ultra-low power supply drain current is independent of the power supply voltage. These comparators also feature a common-mode range which includes ground, even when operated from a single supply. Applications include limit comparators, simple analog-to-digital converters, pulse, square and time delay generators; multivibrators; high voltage logic gates. The lp339mx was specifically designed to interface with the CMOS logic family. The ultra-low supply current makes the lp339mx valuable in battery powered applications.

Parametrics

lp339mx absolute maximum ratings: (1)Supply Voltage: 36 VDC or ±18 VDC; (2)Differential Input Voltage: ±36 VDC; (3)Input Voltage: -0.3 VDC to 36 VDC; (4)Power Dissipation (Note 2) Molded DIP: 570 mW; (5)Input Current VIN<.0.3 VDC (Note 4): 50 mA; (6)Operating Temperature Range: 0℃ to +70℃; (7)Storage Temperature Range: -65℃ to +150℃.

Features

lp339mx features: (1)Low input biasing current: 3 nA; (2)Low input offset current: ±0.5 nA; (3)Low input offset voltage: ±2 mV; (4)Input common-mode voltage includes ground; (5)Output voltage compatible with MOS and CMOS logic; (6)High output sink current capability (30 mA at VO=2 VDC); (7)Supply Input protected against reverse voltages.
