LM324MX

LM324MX, operational amplifier, 32V, 800 mW, 50 mA, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.34~0.34 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 5000 :	0.34 / Piece

PartNumber:: LM324MX

Brand:: National Semiconductor - NS | Pack: | D/C: 10+

Availability:: Supply Ability: 5000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-09-24

From Other Seller

Part Number:LM324MX
US $0.34 - 0.34
Quantity:

piece

Product Summary

The lm324mx is an independent, high gain, internally frequency compensated operational amplifier which were designed specifically to operate from a single power supply over a wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. Application areas include transducer amplifiers, DC gain blocks and all the conventional op amp circuits which now can be more easily implemented in single power supply systems. For example, the lm324mx can be directly operated off of the standard +5V power supply voltage which is used in digital systems and will easily provide the required interface electronics without requiring the additional ±15V power supplies.

Parametrics

lm324mx absolute maximum ratings: (1)Supply Voltage, V+: 32V; (2)Differential Input Voltage: 32V; (3)Input Voltage: -0.3V to +32V; (4)Input Current, (VIN < .0.3V): 50 mA; (5)Power Dissipation, Molded DIP: 1130 mW; (6)Cavity DIP: 1260 mW; (7)Small Outline Package: 800 mW; (8)Output Short-Circuit to GND: Continuous Continuous; (9)Operating Temperature Range: -40℃ to +85℃: 0℃ to +70℃; (10)Storage Temperature Range: -65℃ to +150℃; (11)Lead Temperature (Soldering, 10 seconds): 260℃; (12)ESD Tolerance: 250V.

Features

lm324mx features: (1)Internally frequency compensated for unity gain; (2)Large DC voltage gai100 dB; (3)Wide bandwidth (unity gain) 1 MHz (temperature compensated); (4)Wide power supply range: Single supply 3V to 32V or dual supplies ±1.5V to ±16V; (5)Very low supply current drai(700 μA)-essentially independent of supply voltage; (6)Low input biasing current 45 nA (temperature compensated); (7)Low input offset voltage 2 mV and offset current: 5 nA; (8)Input common-mode voltage range includes ground; (9)Differential input voltage range equal to the power supply voltage; (10)Large output voltage swing 0V to V+ -1.5V.
