HIN232CP

HIN232CP, RS-232 transmitter/receiver interface circuit, 6V, 120kbps, 300Ω, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.73~0.73 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 200 :	0.73 / Piece

PartNumber:: HIN232CP

Brand:: Harris Corporation - Harris | Pack: DIP | D/C: 01+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-01

From Other Seller

Part Number:HIN232CP
US $0.73 - 0.73
Quantity:

piece

Product Summary

The hin232cp is a +5V powered RS-232 transmitter/receiver interface circuit. The hin232cp meets all ElA high-speed RS-232E and V.28 specifications, and is particularly suited for those applications where ±12V is not available. The HIN232CP requires a single +5V power supply and feature onboard charge pump voltage converters which generate +10V and -10V supplies from the 5V supply. The applications of the HIN232CP include Any System Requiring RS-232 Communication Ports: Computer - Portable, Mainframe, Laptop; Peripheral - Printers and Terminals; Instrumentation; Modems.

Parametrics

hin232cp absolute maximum ratings: (1)VCC to Ground: (GND -0.3V)

Features

hin232cp features: (1)Meets All RS-232E and V.28 Specifications; (2)Requires Only Single +5V Power Supply - (+5V and +12V - HIN239); (3)High Data Rate: 120kbps; (4)Onboard Voltage Doubler/Inverter; (5)Low Power Consumption; (6)Low Power Shutdown Function; (7)Three-State TTL/CMOS Receiver Outputs; (8)Multiple Drivers: ±10V Output Swing for 5V input; 300Ω Power-Off Source Impedance; Output Current Limiting; TTL/CMOS Compatible; 30V/μs Maximum Slew Rate; (9)Multiple Receivers: ±30V Input Voltage Range; 3kΩ to 7kΩ Input Impedance; 0.5V Hysteresis to Improve Noise Rejection; (10)Pb-free Available (RoHS compliant).
