Product Summary
The g2996f1uf is a linear regulator designed to meet the JEDEC SSTL-18 ,SSTL-2 and SSTL-3 (series stub termination logic) specifications for termination of DDR-SDRAM. The g2996f1uf contains a high-speed operational amplifier that provides excellent response to the load transients. The g2996f1uf can deliver 1.5A/0.9A continuous current and transient peaks up to 3A/1.8A in the application as required for DDRI/II-SDRAM termination. With an independent VSENSE pin, the g2996f1uf can provide superior load regulation. The g2996f1uf provides a VREF output as the reference for the applications of the chipset and DIMMs. Applications are (1)DDR-SDRAM termination voltage; (2)DDR-I / DDR-II termination voltage; (3)SSTL-2; (4)SSTL-3.
Parametrics
g2996f1uf absolute maximum ratings: (1)Supply voltage, PVIN, AVIN, VDDQ to GND: -0.3V to +6V; (2)Operating ambient temperature range, TA: -40°C to +125°C; (3)Maximum junction temperature, TJ: 150°C; (4)Storage temperature range, TSTG: -65°C to+150°C; (5)Reflow temperature (soldering, 10 sec): 260°C; (6)Electrostatic discharge, VESD human body mode: 2000V(2); (7)Thermal resistance junction to ambient, (θJA), SOP-8: 130°C/W; SOP-8 (FD): 110°C/W(3); SOP-8 (FD): 50°C/W(4); SOP-8 (FD): 41°C/W(5); (8)Thermal resistance junction to case, (θJC)SOP-8 (FD): 12°C/W.
Features
g2996f1uf features: (1)Operation supply voltage: 1.6V to 5.5V; (2)Low supply current: 280μA @ 2.5V; (3)Low output offset; (4)Source and sink current; (5)Low external component count; (6)No inductor required; (7)No external resistors required; (8)Thermal shutdown protection; (9)Suspend to RAM (STR)function; (10)SOP-8 with power-pad package.
Diagrams
