DS32KHZN/DIP

DS32KHZN/DIP, temperature-compensated crystal oscillator, 7.0V, 50 nA, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.89~4.89 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 200 :	4.89 / Piece

PartNumber:: DS32KHZN/DIP

Brand:: Dallas Semiconductor - Maxim | Pack: DIP | D/C: 99+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-01

From Other Seller

Part Number:DS32KHZN/DIP
US $4.89 - 4.89
Quantity:

piece

Product Summary

The ds32khzn/dip is a temperature-compensated crystal oscillator (TCXO) with an output frequency of 32.768kHz. The ds32khzn/dip addresses applications requiring better timekeeping accuracy, and can be used to drive the X1 input of most Dallas Semiconductor real-time clocks (RTCs), chipsets, and other ICs containing RTCs. Applications are (1)GPS Receivers; (2)Telematics; (3)Network Timing and Synchronization in Servers, Routers, Hubs, and Switches; (4)Automatic Power Meters.

Parametrics

ds32khzn/dip absolute maximum ratings: (1)Voltage Range on Any Pin Relative to Ground: -3.0V to +7.0V; (2)Operating Temperature Range (Noncondensing)Commercial: 0°C to +70°C, Industrial: -40°C to +85°C; (3)Storage Temperature Range: -40°C to +85°C; (4)Soldering Temperature (BGA, SO): See the Handling, PC Board Layout, and Assembly section.; (5)Soldering Temperature, Leads (DIP): +260°C for 10 seconds.

Features

ds32khzn/dip features: (1)Accurate to ±4 Minutes/Year (-40°C to +85°C); (2)Accurate to ±1 Minute/Year (0°C to +40°C); (3)Battery Backup for Continuous Timekeeping; (4)VBAT Operating Voltage: 2.7V to 5.5V with VCC Grounded; (5)VCC Operating Voltage: 4.5V to 5.5V; (6)Operating Temperature Range: 0°C to +70°C (Commercial), -40°C to +85°C (Industrial); (7)No Calibration Required; (8)Low-Power Consumption; (9)Surface Mountable Using BGA Package; (10)UL Recognized.
