DG441LDY

analog switch, 17Ω, 13V, 100mA, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.49~0.49 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 200 :	0.49 / Piece

PartNumber:: DG441LDY

Brand:: Silicon image - Silicon | Pack: SOIC | D/C: 02+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-03

From Other Seller

Part Number:DG441LDY
US $0.49 - 0.49
Quantity:

piece

Product Summary

The DG441LDY is a low voltage pin-for-pin compatible companion device to the industry standard the DG441LDY with improved performance. Using BiCMOS wafer fabrication technology allows the DG441LDY to operate on single and dual supplies. Applications of the DG441LDY include: Precision Automatic Test Equipment, Precision Data Acquisition, Communication Systems, Battery Powered Systems, Computer Peripherals, SDSL, DSLAM, Audio and Video Signal Routing.

Parametrics

DG441LDY absolute maximum ratings: (1) V+-V-: -0.3 to 13V; (2) GND to V-: 7V; (3) Digital Inputs Vs, VD: GND -0.3 to (V+ +0.3V) ; (4) Continuous Current (Any Terminal) : 30mA; (5) Current, S or D (Pulsed 1 ms, 10% duty cycle) : 100mA; (6) Storage Temperature: (DQ, DY Suffix: -65 to +125°C, (AK Suffix) : -65 to +150°C; (7) Power Dissipation (Package)b : 650mW.

Features

DG441LDY features: (1) 2.7- thru 12-V Single Supply or ±3-thru ±6-Dual Supply; (2) On-Resistance-IDS (on) : 17Ω; (3) Fast Switching-tON: 20ns, -tOFF: 12ns; (4) TTL, CMOS Compatible; (5) Low Leakage: 0.25nA; (6) 2000V ESD Protection.
