Product Summary

The byv26c-tap is a fast soft-recovery controlled avalanche rectifier. This package is hermetically sealed and fatigue free as coefficients of expansion of all used parts are matched. The byv26c-tap uses a high temperature alloyed construction.

Parametrics

byv26c-tap absolute maximum ratings: (1)repetitive peak reverse voltage: 600V; (2)continuous reverse voltage: 600V; (3)average forward current: 1A; (4)average forward current: 0.65A; (5)repetitive peak forward current: 10A.

Features

byv26c-tap features: (1)Glass passivated; (2)High maximum operating temperature; (3)Low leakage current; (4)Excellent stability; (5)Guaranteed avalanche energy absorption capability; (6)Available in ammo-pack.

Diagrams

byv26c-tap circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BYV26C-TAP
BYV26C-TAP

Vishay Semiconductors

Rectifiers 1 Amp 600 Volt 30 Amp IFSM

Data Sheet

0-1: $0.16
1-10: $0.15
10-100: $0.13
100-250: $0.13
