Product Summary
The SN74AHCT1G04DBVR is an evaluation module built to the TI Modular EVM System specification. It can be connected to any modular EVM system interface card. The SN74AHCT1G04DBVR is available as a stand-alone printed circuit board (PCB) or as part of the ADS1248EVM-PDK, which includes an MMB3 motherboard and software. As a stand-alone PCB, the SN74AHCT1G04DBVR is useful for prototyping designs and firmware. Note that the SN74AHCT1G04DBVR has no microprocessor and cannot run software. To connect it to a computer, some type of interface is required.
Features
SN74AHCT1G04DBVR features: (1)Contains all support circuitry needed for the ADS1148/ADS1248; (2)±2.5V and +5V power-supply options for ADC; (3)Voltage reference options: external or onboard; (4)GPIO access; (5)Compatible with the TI Modular EVM System; (6)Easy-to-use evaluation software for Microsoft Windows XP; (7)Data collection to text files; (8)Built-in analysis tools including scope, FFT, and histogram displays; (9)Complete control of board settings; (10)Easily expandable with new analysis plug-in tools from Texas Instruments.
