B560C-13-F

B560C-13-F, surface mount schottky barrier rectifier, 60V, 5.0 A, 300 pF, SOD

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~0.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	0.10 / Piece

PartNumber:: B560C-13-F

Brand:: Diodes Incorporated - Diodes | Pack: SOD | D/C: 10+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-24

From Other Seller

Part Number:B560C-13-F
US $0.10 - 0.10
Quantity:

piece

Product Summary

The B560C-13-F is a 5.0A surface mount schottky barrier rectifier.

Parametrics

B560C-13-F absolute maximum ratings: (1)Peak Repetitive Reverse Voltage, VRRM: 60V; (2)Working Peak Reverse Voltage, VRWM: 42V; (3)DC Blocking Voltage, VR: 40V; (4)RMS Reverse Voltage, VR(RMS): 28V; (5)Average Rectified Output Current @ TT = 90℃, IO: 5.0 A; (6)Non-Repetitive Peak Forward Surge Current, 8.3 ms single half-sine-wave Superimposed on Rated Load (JEDEC method), IFSM: 175 A; (7)Forward Voltage @ IF = 5.0A DC, VFM: 0.55V; (8)Peak Reverse Current @TA = 25℃ at Rated DC Blocking Voltage @ TA = 100℃, IRM: 0.5mA; (9)Typical Junction Capacitance, Cj: 300 pF; (10)Typical Thermal Resistance, Junction to Terminal, RθJT: 10 K/W; (11)Typical Thermal Resistance, Junction to Ambient, RθJA: 50℃/W; (12)Operating Temperature Range, Tj: -55 to +125℃; (13)Storage Temperature Range, TSTG: -55 to +150℃.

Features

B560C-13-F features: (1)Guard Ring Die Construction for Transient Protection; (2)Ideally Suited for Automatic Assembly; (3)Low Power Loss, High Efficiency; (4)Surge Overload Rating to 175A Peak; (5)For Use in Low Voltage, High Frequency Inverters, Free Wheeling, and Polarity Protection Application; (6)Plastic Material - UL Flammability Classification 94V-0.
