IR3082MTRPBF

IR3082MTRPBF, Control IC, 110 dB, 1 mA, 400 Hz, QFN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.00 / Piece

PartNumber:: IR3082MTRPBF

Brand:: International Rectifier - IR | Pack: QFN | D/C: 06+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-24

From Other Seller

Part Number:IR3082MTRPBF
US $1.00 - 1.00
Quantity:

piece

Product Summary

The IR3082MTRPBF Control IC combined with an IR XPhaseTM Phase IC provides a full featured and flexible way to implement a complete Opteron or Athlon64 power solution. The IR3082MTRPBF provides overall system control and interfaces with any number of Phase ICs which each drive and monitor a single phase of a multiphase converter. With simple 5 bit voltage programming and a few external components, the IR3082MTRPBF is also well suited for general purpose multiphase applications. The XPhaseTM architecture results in a power supply that is smaller, less expensive, and easier to design while providing higher efficiency than conventional approaches.

Parametrics

IR3082MTRPBF absolute maximum ratings: (1)Operating Junction Temperature: 150oC; (2)Storage Temperature Range: -65°C to 150°C; (3)DC Gain: 90 to 110 dB; (4)Gain Bandwidth Product: 6 to 10 MHz; (5)Corner Frequency 45 deg Phase Shift: 400 Hz; (6)Slew Rate: 1.4 to 5 V/μs; (7)Source Current: 0.4 to 1 mA.

Features

IR3082MTRPBF features: (1)5 bit VID with 1% overall system set point accuracy; (2)Programmable Dynamic VID Slew Rate; (3)+/-300mV Differential Remote Sense; (4)Programmable 150kHz to 1MHz oscillator; (5)Programmable VID Offset and Load Line output impedance; (6)Programmable Softstart; (7)Programmable Hiccup Over-Current Protection with Delay to prevent false triggering; (8)Simplified Power Good output provides indication of proper operation and avoids false triggering; (9)Operates from 12V input with 9.75V Under-Voltage Lockout; (10)7.0V/5mA Bias Regulator provides System Reference Voltage; (11)Small thermally enhanced 20L MLPQ package.
