AM29LV001BB-70EC

AM29LV001BB-70EC, Flash memory device, 3.0 Volt, 5 MHz, 0.35 μm, 200 mA, TSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	3.00 / Piece

PartNumber:: AM29LV001BB-70EC

Brand:: Advanced Micro Devices - AMD | Pack: TSOP | D/C: 09+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-20

From Other Seller

Part Number:AM29LV001BB-70EC
US $3.00 - 3.00
Quantity:

piece

Product Summary

The AM29LV001BB-70EC is a 1 Mbit, 3.0 Volt-only Flash memory device organized as 131,072 bytes. The AM29LV001BB-55EC has a boot sector architecture. The AM29LV001BB-70EC is offered in 32-pin PLCC and 32-pin TSOP packages. The byte-wide (x8) data appears on DQ7– DQ0. All read, erase, and program operations are accomplished using only a single power supply. The AM29LV001BB-70EC can also be programmed in standard EPROM programmers.

Parametrics

AM29LV001BB-70EC absolute maximum ratings: (1)Storage Temperature Plastic Packages: –65°C to +150°C; (2)Ambient Temperature with Power Applied: –65°C to +125°C; (3)Voltage with Respect to Ground All pins except A9, OE# and RESET# : –0.5 V to VCC+0.5 V, VCC: –0.5 V to +3.6 V; (4)A9, OE#, and RESET#: –0.5 V to +12.5 V; (5)Output Short Circuit Current: 200 mA.

Features

AM29LV001BB-70EC features: (1)Single power supply operation; (2)Manufactured 0.35 μm process technology; (3)High performance; (4)Ultra low power consumptio(typical values at 5 MHz); (5)Unlock Bypass Mode Program Command; (6)Top or bottom boot block configurations available; (7)Embedded Algorithms; (8)Minimum 1,000,000 write cycle guarantee per sector; (9)Package option; (10)Compatibility with JEDEC standards; (11)Data# Polling and toggle bits; (12)Erase Suspend/Erase Resume.
