Product Summary

The NTF2955T1 is a Single P-Channel Power MOSFET. It is widely used in: (1)Power Supplies; (2)PWM Motor Control; (3)Converters; (4)Power Management.

Parametrics

NTF2955T1 absolute maximum ratings: (1)Drain.to.Source Voltage VDSS: -60 V; (2)Gate.to.Source Voltage VGS: ¡À20 V; (3)Pulsed Drain Current tp = 10us IDM: -17 A; (4)Operating Junction and Storage Temperature: TJ, TSTG: -55 to 175℃; (5)Single Pulse Drain.to.Source Avalanche Energy (VDD = 25 V, VG = 10 V, IPK = 6.7 A, L = 10 mH, RG = 25m¸), EAS: 225 mJ; (6)Lead Temperature for Soldering Purposes (1/8" from case for 10 seconds), TL: 260℃.

Features

NTF2955T1 features: (1)Design for low RDS(on); (2)Withstands High Energy in Avalanche and Commutation Modes; (3)AEC-Q101 Qualified - NVF2955, NVF2955P; (4)These Devices are Pb-Free and are RoHS Compliant.

Diagrams

NTF2955T1 circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
NTF2955T1
NTF2955T1

ON Semiconductor

MOSFET -60V 2.6A P-Channel

Data Sheet

Negotiable
NTF2955T1G
NTF2955T1G

ON Semiconductor

MOSFET -60V 2.6A P-Channel

Data Sheet

0-1: $0.56
1-25: $0.44
25-100: $0.38
100-500: $0.28
500-1000: $0.23
