IRF6628TRPBF

IRF6628TRPBF, DirectFET Power MOSFET, SO-8, 25V, 220A

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.00 / Piece

PartNumber:: IRF6628TRPBF

Brand:: International Rectifier - IR | D/C: 07+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-24

From Other Seller

Part Number:IRF6628TRPBF
US $1.00 - 1.00
Quantity:

piece

Product Summary

The IRF6628TRPBF is a kind of DirectFET Power MOSFET, which combines the latest HEXFET Power MOSFET Silicon technology with the advanced DirectFETTM packaging to achieve the lowest on-state resistance in a package that has the footprint of an SO-8 and only 0.6 mm profile. The DirectFET package is compatible with existing layout geometries used in power applications, PCB assembly equipment and vapor phase, infra-red or convection soldering techniques, when application note AN-1035 is followed regarding the manufacturing methods and processes. The DirectFET package of the IRF6628TRPBF allows dual sided cooling to maximize thermal transfer in power systems, improving previous best thermal resistance by 80%.

Parametrics

IRF6628TRPBF absolute maximum ratings: (1)Drain-Source Voltage VDS: 25V; (2)Gate-Source Voltage VGS: ±20V; (3)Continuous Drain Current, VGS @ 10V, ID @ TA = 25℃ : 27A; (4)Continuous Drain Current, VGS @ 10V, ID @ TA = 70℃ : 22A; (5) Pulsed Drain Current. IDM: 220A; (6)IAR, Avalanche Current: 22 A.

Features

IRF6628TRPBF features: (1)RoHs Compliant; (2)Lead-Free (Qualified up to 260°C Reflow); (3)Application Specific MOSFETs; (4)Ideal for CPU Core DC-DC Converters; (5)Low Conduction Losses; (6)High Cdv/dt Immunity; (7)Low Profile (<0.7mm); (8)Dual Sided Cooling Compatible; (9)Compatible with existing Surface Mount Techniques.
