Product Summary

The AO3415 is a 20V P-channel MOSFET. The AO3415 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 1.8V. The AO3415 is suitable for use as a load switch applications.

Parametrics

AO3415 absolute maximum ratings: (1)Drain-source voltage, VDS: -20 V; (2)Gate-source voltage, Vgs: ±8 V; (3)Continuous drain current, Ta=25 ℃: -4 A; Ta=70 ℃,ID: -3.5 A; (4)Pulsed drain current: IDM: -30 A; (5)Power dissipation, Ta=25 ℃, PD: 1.5 W; Ta=70 ℃, PD: 1 W; (6)Junction and storage temperature range,Tj, Tstg: -55 to 150 ℃.

Features

AO3415 features: (1)VDS: -20 V; (2)ID (at VGS=-4.5V): -4 A; (3)RDS(ON)(at VGS= -4.5V): < 41 mΩ; (4)RDS(ON)(at VGS= -2.5V): < 53 mΩ; (5)RDS(ON)(at VGS= -1.8V): < 65 mΩ.

Diagrams

AO3415 pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
AO3415AL
AO3415AL

Other


Data Sheet

Negotiable
AO3415A
AO3415A


MOSFET P-CH 20V 4A SOT23-3

Data Sheet

0-1: $0.29
1-25: $0.19
25-100: $0.15
100-250: $0.13
250-500: $0.11
500-1000: $0.08
AO3415
AO3415


MOSFET P-CH -20V -4.0A SOT23

Data Sheet

0-1: $0.29
1-25: $0.19
25-100: $0.15
100-250: $0.13
250-500: $0.11
500-1000: $0.08
