Product Summary

The BTA08 is an 8A Triacs. The bta08 is suitable for general purpose AC switching. The bta08 can be used as an ON/OFF function in applications such as static relays, heating regulation, induction motor starting circuits.

Parametrics

BTA08 absolute maximum ratings: (1)I t Value for fusing:45As; (2)Critical rate of rise of on-state current IG =2xIGT ,tr ≤ 100 ns:50 A/μs; (3)Peak gate current:4 A; (4)Average gate power dissipation:1 W; (5)Storage junction temperature range:- 40℃ to + 150℃; (6)Operating junction temperature range:- 40℃ to + 125℃.

Features

BTA08 features: (1)IT(RMS):8A; (2)VDRM/VRRM:600V and 800V; (3)IGT (Q1):5mA to 50mA.

Diagrams

BTA08 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BTA08-600TWRG
BTA08-600TWRG
STMicroelectronics
Triacs 8 Amp 600 Volt
Data Sheet
0-1: $0.91
1-10: $0.73
10-100: $0.64
100-250: $0.56
BTA08-600CWRG
BTA08-600CWRG
STMicroelectronics
Triacs 8 Amp 600 Volt
Data Sheet
0-1: $0.73
1-10: $0.68
10-100: $0.59
100-250: $0.52
BTA08-600SWRG
BTA08-600SWRG
STMicroelectronics
Triacs 8 Amp 600 Volt
Data Sheet
0-1: $0.85
1-10: $0.68
10-100: $0.59
100-250: $0.52
BTA08-800CW3LFG
BTA08-800CW3LFG
ON Semiconductor
Triacs
Data Sheet
0-1: $0.97
1-25: $0.77
25-100: $0.68
100-500: $0.53
BTA08-800BW3G
BTA08-800BW3G
ON Semiconductor
Triacs 8A 50mA 800V IGT 3 QUAD INTERNL ISLTD
Data Sheet
0-1: $0.54
1-25: $0.53
25-100: $0.42
100-250: $0.38
BTA08-800CRG
BTA08-800CRG
STMicroelectronics
Triacs 8 Amp 800 Volt
Data Sheet
0-630: $0.49
630-1000: $0.45
1000-2000: $0.42
2000-5000: $0.40
BTA08-800BWRG
BTA08-800BWRG
STMicroelectronics
Triacs 8 Amp 800 Volt
Data Sheet
0-730: $0.43
730-1000: $0.40
BTA08-700CWRG
BTA08-700CWRG
STMicroelectronics
Triacs 8 Amp 700 Volt
Data Sheet
0-650: $0.47
650-1000: $0.44
1000-2000: $0.41
2000-5000: $0.40
