BSO4420

BSO4420, OptiMOS small-signal-transistor, 13 A, 2.5 W, 20 V, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.00 / Piece

PartNumber:: BSO4420

Brand:: Infineon Technologies - Infineon | D/C:

Availability:: Supply Ability: 5/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-03

From Other Seller

Part Number:BSO4420
US $1.00 - 1.00
Quantity:

piece

Product Summary

The BSO4420 is an optiMOS small-signal-transistor.

Parametrics

BSO4420 absolute maximum ratings: (1)Continuous drain current TA=25°C, ID: 13 A; (2)Pulsed drain current TA=25°C, ID puls: 52 A; (3)Avalanche energy, single pulse ID=13 A , VDD=25V, RGS=25Ω, EAS: 230 mJ; (4)Reverse diode dv/dt IS=13A, VDS=24V, di/dt=200A/μs, Tjmax=150°C, dv/dt: 6 kV/μs; (5)Gate source voltage, VGS: ±20 V; (6)Power dissipation TA=25°C, Ptot: 2.5 W; (7)Operating and storage temperature, Tj , Tstg -55 to +150 °C; (8)IEC climatic category; DIN IEC 68-1: 55/150/56.

Features

BSO4420 features: (1)N-channel; (2)Logic level; (3)Very low on-resistance RDS(on); (4)Excellent gate charge x RDS(on)product (FOM); (5)Avalanche rated; (6)dv/dt rated; (7)Ideal for fast switching applications.
