2SJ378

2sj378, Silicon P Channel MOS Type Transistor, -60V, -5A, 1.3W

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.13~0.13 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 33000 :	0.13 / Piece

PartNumber:: 2SJ378

Brand:: Toshiba Semiconductor - Toshiba | D/C: 03+

Availability:: Supply Ability: 33000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-09

From Other Seller

Part Number:2SJ378
US $0.13 - 0.13
Quantity:

piece

Product Summary

The 2sj378 is a kind of Silicon P Channel MOS Type Transistor for Relay Drive, DC-DC Converter and Motor Drive Applications.

Parametrics

2sj378 absolute maximum ratings: (1)Drain-Source-Voltage, VDS: -60 V; (2)Drain-Gate-Voltage (RGS=20KW), VDGR: -60 V; (3)Continous Drain Current, ID: -5 A; (4)Pulsed Drain Current, ID(puls): -20 A; (5)Gate-Source-Voltage, VGS: 20 V; (6)Max. Power Dissipation, PD: 1.3 W; (7)Operating and Storage Temperature Range, Tch: 150℃; Tstg: -55 to +150℃.

Features

2sj378 features: (1)4 V gate drive; (2)Low drain.source ON resistance : RDS (ON) = 0.16Ω (typ.); (3)High forward transfer admittance : |Yfs| = 4.0 S (typ.); (4)Low leakage current : IDSS = .100 uA (max) (VDS = .60 V); (5)Enhancement.mode : Vth = .0.8~.2.0 V (VDS = .10 V, ID = .1 mA).
