TLE4286G

tle4286g, fixed voltage regulator, 45 V, 20 mA, SC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.29~0.29 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 8500 :	0.29 / Piece

PartNumber:: TLE4286G

Brand:: eupec GmbH - infineon | Pack: | D/C: 08+

Availability:: Supply Ability: 8500/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-09-11

From Other Seller

Part Number:TLE4286G
US $0.29 - 0.29
Quantity:

piece

Product Summary

The tle4286g is a 5-V low-drop fixed voltage regulator in the very small SMD package PG-SCT-595-5. The maximum input voltage is 42 V. The output is able to drive a load of more than 10 mA while it regulates the output voltage within a 4% accuracy.

Parametrics

tle4286g absolute maximum ratings: (1)Input Voltage: -0.3 to 45 V; (2)Input Current: -20 mA min; (3)Output Voltage: -0.3 to 16 V; (4)Output Current: -20 mA min; (5)Junction temperature: -40 to 150 ℃; (6)Storage temperature: -50 to 150 ℃.

Features

tle4286g features: (1)15 mA output current capability; (2)1 μA current consumption in standby mode; (3)Low quiescent current consumption 60 μA in ON mode Inhibit input; (4)Very small SMD-Package PG-SCT-595-5; (5)Wide operation range: 6.2 V to 42 V; (6)Wide temperature range: -40 ℃ to 150 ℃; (7)Output protected against short circuit; (8)Overtemperature protection; (9)Green product (RoHS compliant); (10)AEC qualified.
