Product Summary
The X9241AUPI integrates four digitally controlled potentiometer (XDCP) on a monolithic CMOS integrated microcircuit. The contents of the WCR controls the position of the wiper on the resistor array through the switches. Power up recalls the contents of DR0 to the WCR. The X9241AUPI can be used as a three-terminal potentiometer or as a two-terminal variable resistor in a wide variety of applications including control, parameter adjustments, and signal processing.
Parametrics
X9241AUPI absolute maximum ratings: (1)Temperature under bias : –65 to +135°C; (2)Storage temperature : –65 to +150°C; (3)Voltage on SCK, SCL or any address input with respect to VSS: –1V to +7V; (4)Voltage on any VH/RH, VW/RW or VL/RL referenced to VSS: +6V/-4V; (5)ΔV = |VH/RH–VL/RL| : 10V; (6)Lead temperature (soldering, 10 seconds): 300°C; (7)IW (10 seconds): ±6mA.
Features
X9241AUPI features: (1)Four potentiometers in one package; (2)2-wire serial interface; (3)Register oriented format; (4)Terminal Voltages: +5V, -3.0V; (5)Cascade resistor arrays; (6)Low power CMOS; (7)High Reliability; (8)16-bytes of nonvolatile memory; (9)3 resistor array values; (10)Resolution: 64 taps each pot; (11)20-lead plastic DIP, 20-lead TSSOP and 20-lead SOIC packages.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 X9241AUPI |
|
IC XDCP QUAD 4X50K EE 20-DIP |
Data Sheet |
Negotiable |
|
||||||
|
X9241AUPIZ |
|
IC XDCP QUAD 4X50K EE 20-DIP |
Data Sheet |
|
|
||||||
