TDA2003V

TDA2003V, car radio audio amplifier, 40 V, 3.5 A, 20W, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.31~0.31 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 4000 :	0.31 / Piece

PartNumber:: TDA2003V

Brand:: STMicroelectronics - ST | Pack: | D/C: 11+

Availability:: Supply Ability: 4000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-09-11

From Other Seller

Part Number:TDA2003V
US $0.31 - 0.31
Quantity:

piece

Product Summary

The TDA2003V is a car radio audio amplifier. The TDA2003V has improved performancewith the same pin configuration as the TDA 2002. The additional features of the TDA2003V, very low numberof externalcomponents,ease of assembly, space and cost saving, are maintained. The TDA2003V provides high outputcurrentcapability (up to 3.5A) very low harmonic and cross-over distortion. Completely safe operation is guaranteed due to protectionagainstDCand ACshort circuit between all pins and ground,thermal over-range,load dump voltage surge up to 40V and fortuitous open ground.

Parametrics

TDA2003V absolute maximum ratings: (1)Peak supply voltage (50ms):40 V; (2)DC supply voltage:28 V; (3)Operating supply voltage:18 V; (4)Output peak current (repetitive):3.5 A; (5)Output peak current (non repetitive):4.5 A; (6)Power dissipation at Tcase = 90℃:20W; (7)Storage and junction temeperature -40℃ to 150℃.

Features

TDA2003V features: (1)Supply voltage:8 to 18V; (2)Quiescent output voltage (pin 4): 6.1 to 7.7V; (3)Quiescent drain current (pin 5):44 to 50mA; (4)frequency response:40Hz to 15000Hz; (5)input resistance:70kΩ to 150kΩ; (6)voltage gain:39.3dB to 40.3dB; (7)input noise voltage:1uV to 5uV; (8)input noise current:60pA to 200pA; (9)supply voltage rejection:30dB to 36dB.
