SN74LVC1G04DCKR

single inverter gate, 100mA, 5.5V, BGA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.04~0.04 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3000 :	0.04 / Piece

PartNumber:: SN74LVC1G04DCKR

Brand:: Texas Instruments - TI | Pack: BGA | D/C: 10+

Availability:: Supply Ability: 3000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-15

From Other Seller

Part Number:SN74LVC1G04DCKR
US $0.04 - 0.04
Quantity:

piece

Product Summary

The sn74lvc1g04dckr is a single inverter gate. The SN74LVC1G04DCKR is designed for 1.65-V to 5.5-V VCC operation. performs the Boolean function Y=A. The SN74LVC1G04DCKR is fully specified for partial-power-down applications using Ioff.

Parametrics

sn74lvc1g04dckr absolute maximum ratings: (1) Supply voltage range Vcc: -0.5 to 6.5V; (2) Input voltage range VI: -0.5 to 6.5V; (3) Voltage range applied to any output in the high-impedance or power-off state Vo: -0.5 to 6.5V; (4) Voltage range applied to any output in the high or low state Vo: -0.5 to Vcc +0.5V; (5) Input clamp current IIK: -50mA (VI< 0) ; (6) Output clamp current IOK: -50mA (Vo< 0) ; (7) Continuous output current IO: ±50mA; (8) Continuous current through Vcc or GND: ±100mA; (9) Storage temperature range Tstg: -65 to +150°C

Features

sn74lvc1g04dckr features: (1) Available in the Texas Instruments NanoStar and NanoFree Packages; (2) Supports 5-V Vcc Operation; (3) Inputs Accept Voltages to 5.5 V; (4) Max tpd of 3.3 ns at 3.3 V; (5) Low Power Consumption, 10-μA Max ICC; (6) ±24-mA Output Drive at 3.3 V; (7) Ioff Supports Partial-Power-Down Mode Operation; (8) Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II; (9) ESD Protection Exceeds JESD 22.
