SN74HCT04PWR

SN74HCT04PWR, independent inverter, 7 V, 50 mA, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.07~0.07 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 6000 :	0.07 / Piece

PartNumber:: SN74HCT04PWR

Brand:: Texas Instruments - TI | Pack: | D/C: 10+

Availability:: Supply Ability: 6000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-22

From Other Seller

Part Number:SN74HCT04PWR
US $0.07 - 0.07
Quantity:

piece

Product Summary

The sn74hct04pwr is an independent inverter. The sn74hct04pwr performs the Boolean function Y = A in positive logic.

Parametrics

sn74hct04pwr absolute maximum ratings: (1)Supply voltage range, VCC: –0.5 V to 7 V; (2)Input clamp current, IIK (VI < 0 or VI > VCC): ±20 mA; (3)Output clamp current, IOK (VO < 0 or VO > VCC): ±20 mA; (4)Continuous output current, IO (VO = 0 to VCC): ±25 mA; (5)Continuous current through VCC or GND: ±50 mA; (6)Storage temperature range, Tstg: –65°C to 150°C.

Features

sn74hct04pwr features: (1)Operating Voltage Range of 4.5 V to 5.5 V; (2)Outputs Can Drive Up To 10 LSTTL Loads; (3)Low Power Consumption, 20-μA Max ICC; (4)Typical tpd = 13 ns; (5)±4-mA Output Drive at 5 V; (6)Low Input Current of 1 μA Max; (7)Inputs Are TTL-Voltage Compatible.
