MP1482DS-LF-Z

MP1482DS-LF-Z, monolithic synchronous buck regulator, 4.75V, 3.4A, 340kHz, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.14~0.14 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.14 / Piece

PartNumber:: MP1482DS-LF-Z

Brand:: Monolithic Power Systems - MPS | Pack: | D/C: 11+

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-12

From Other Seller

Part Number:MP1482DS-LF-Z
US $0.14 - 0.14
MP1482DS-LF-Z

US $1.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MP1482DS-LF-Z is a monolithic synchronous buck regulator. The MP1482DS-LF-Z integrates two 130m MOSFETs, and provides 2A of continuous load current over a wide input voltage of 4.75V to 18V. Current mode control provides fast transient response and cycle-by-cycle current limit. An adjustable soft-start prevents inrush current at turn-on, and in shutdown mode the supply current drops to 1 μA. The MP1482DS-LF-Z, available in an 8-pin SOIC package, provides a very compact solution with minimal external components.

Parametrics

MP1482DS-LF-Z absolute maximum ratings: (1)Vin (Min): 4.75V; (2)Vin (Max): 18V; (3)lout (Max): 2A; (4)Isw Typ: 3.4A; (5)Iq (Typ): 1.3mA; (6)Vfb: 0.923V; (7)Freq 1: 340kHz.

Features

MP1482DS-LF-Z features: (1)2A output current; (2)Wide 4.75V to 18V operating input range; (3)Integrated 130mΩ power MOSFET switches; (4)Output adjustable from 0.923V to 15V; (5)Up to 93% efficiency; (6)Programmable soft-start; (7)Stable with low ESR ceramic output capacitors; (8)Fixed 340kHz frequency; (9)Cycle-by-Cycle over current protection; (10)Input under voltage lockout.
