MM74HC86MX

mm74hc86mx, exclusive or gate, 9 ns, 6 v, 1 μa, 500 mw, sop

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.08~0.08 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 5000 :	0.08 / Piece

PartNumber:: MM74HC86MX

Brand:: Freescale Semiconductor, Inc - Freescale | Pack: | D/C: 09+

Availability:: Supply Ability: 5000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-25

From Other Seller

Part Number:MM74HC86MX
US $0.08 - 0.08
Quantity:

piece

Product Summary

The mm74hc86mx is an exclusive OR gate. It utilizes advanced silicon-gate CMOS technology to achieve operating speeds similar to equivalent LS-TTL gates while maintaining the low power consumption and high noise immunity characteristic of standard CMOS integrated circuits. The mm74hc86mx gate is fully buffered and have a fanout of 10 LS-TTL loads. The 74HC logic family is functionally as well as pin out compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to VCC and ground.

Parametrics

mm74hc86mx absolute maximum ratings: (1)Supply Voltage (VCC): -0.5 to +7.0V; (2)DC Input Voltage (VIN): -1.5 to VCC +1.5V; (3)DC Output Voltage (VOUT): -0.5 to VCC +0.5V; (4)Clamp Diode Current (IIK, IOK): ±20 mA; (5)DC Output Current, per pin (IOUT): ±25 mA; (6)DC VCC or GND Current, per pin (ICC): ±50 mA; (7)Storage Temperature Range (TSTG): -65°C to +150°C; (8)Power Dissipation (PD)(Note 3): 600 mW; (9)Power Dissipation (PD)S.O. Package only: 500 mW; (10)Lead Temperature (TL)(Soldering 10 seconds): 260°C.

Features

mm74hc86mx features: (1)Typical propagation delay: 9 ns; (2)Wide operating voltage range: 2–6V; (3)Low input current: 1 μA maximum; (4)Low quiescent current: 20 μA maximum (74 Series); (5)Output drive capability: 10 LS-TTL loads.
