MIC5205BM5

MIC5205BM5, linear voltage regulator, 20V, 75 dB, 500 mA, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~0.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3000 :	0.20 / Piece

PartNumber:: MIC5205BM5

Brand:: Master Instrument Corporation - MIC | Pack: SOT | D/C: 00+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-10

From Other Seller

Part Number:MIC5205BM5
US $0.20 - 0.20
Quantity:

piece

Product Summary

The mic5205bm5 is an efficient linear voltage regulator with ultralow- noise output, very low dropout voltage (typically 17mV at light loads and 165mV at 150mA), and very low ground current (600μA at 100mA output). The mic5205bm5 offers better than 1% initial accuracy. Applications are (1)Cellular telephones; (2)Laptop, notebook, and palmtop computers; (3)Battery-powered equipment; (4)PCMCIA VCC and VPP regulation/switching; (5)Consumer/personal electronics; (6)SMPS post-regulator/dc-to-dc modules; (7)High-efficiency linear power supplies.

Parametrics

mic5205bm5 absolute maximum ratings: (1)Supply Input Voltage (VIN): –20V to +20V; (2)Enable Input Voltage (VEN): –20V to +20V; (3)Lead Temperature (soldering, 5 sec.): 260°C; (4)Junction Temperature (TJ): –40°C to +125°C; (5)Storage Temperature (TS): –65°C to +150°C; (6)PSRR Ripple Rejection frequency = 100Hz, IL = 100μA: 75 dB; (7)ILIMIT Current Limit VOUT = 0V: 320 to 500 mA.

Features

mic5205bm5 features: (1)Ultra-low-noise output; (2)High output voltage accuracy; (3)Guaranteed 150mA output; (4)Low quiescent current; (5)Low dropout voltage; (6)Extremely tight load and line regulation; (7)Very low temperature coefficient; (8)Current and thermal limiting; (9)Reverse-battery protection; (10)Zero off-mode current; (11)Logic-controlled electronic enable.
