MB88347LPFV

MB88347LPFV, eight 8-bit D/A converter, 5.0 V, 250 mW, 1.0 mA, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.33~0.33 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1077 :	0.33 / Piece

PartNumber:: MB88347LPFV

Brand:: FUJI electric - FUJI | Pack: SOP | D/C: 97+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-10

From Other Seller

Part Number:MB88347LPFV
US $0.33 - 0.33
Quantity:

piece

Product Summary

The mb88347lpfv incorporates eight 8-bit D/A converter module. The mb88347lpfv operates at low supply voltage in the performance guarantee range from 2.7 to 3.6 V. It also contains an output amplifier, allowing driving at large current. Since the mb88347lpfv inputs data in serial mode, it requires only three control lines for data input and two or more mb88347lpfv units can be cascaded. The MB88347L is function and pin compatible with the MB88347 (5-volt supply voltage model). The MB88347L is the best replacement for electronic variable resistors or screwdriver control resistors.

Parametrics

mb88347lpfv absolute maximum ratings: (1)Supply voltage VCC Based on GND Ta = +25°C: –0.3 to 5.0 V; (2)VDD: –0.3 to 5.0V; (3)Input voltage VIN: –0.3 to VCC + 0.3 V; (4)Output voltage VOUT: –0.3 to VCC + 0.3 V; (5)Power consumption PD: 250 mW; (6)Operating temperature Ta: –20 to +85 °C; (7)Storage temperature Tstg: –55 to +150 °C.

Features

mb88347lpfv features: (1)Ultra-low power consumption (0.5 mW/ch: typical); (2)Low voltage operation (VCC = 2.7 to 3.6 V); (3)Ultra-compact space-saving package (SSOP-16); (4)Contains 8-channel R-2R type 8-bit D/A converter; (5)On-chip analog output amps (sink current max. 1.0 mA, source current max. 1.0 mA); (6)Analog output range from 0 V to VCC; (7)Two separate power supply/ground lines for MCU interface block/operational amplifier output buffer block and D/A converter block; (8)Serial data input, maximum operating speed 2.5 MHz; (9)CMOS process; (10)Package lineup includes DIP 16-pin, SOP 16-pin, SSOP 16-pin.
