MAX4541CSA-T

max4541csa-t, analog switch, 13V, 20mA, 571mW, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.64~0.64 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 279 :	0.64 / Piece

PartNumber:: MAX4541CSA-T

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 02+

Availability:: Supply Ability: 40/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-08

From Other Seller

Part Number:MAX4541CSA-T
US $0.64 - 0.64
Quantity:

piece

Product Summary

The max4541csa-t is a precision, dual analog switch designed to operate from a single +2.7V to +12V supply. Low power consumption (5μW) makes these parts ideal for battery-powered equipment. The max4541csa-t offers low leakage currents (100pA max) and fast switching speeds (tON = 150ns max, tOFF = 100ns max). Applications are (1)Battery-Operated Systems; (2)Sample-and-Hold Circuits; (3)Heads-Up Displays; (4)Guidance and Control; (5)Systems; (6)Audio and Video; (7)Switching; (8)Military Radios; (9)Test Equipment; (10)Communications Systems; (11)+3V/+5V DACs and ADCs; (12)PBX, PABX; (13)Cell Phones; (14)Ultrasound; (15)Pagers.

Parametrics

max4541csa-t absolute maximum ratings: (1)V+: -0.3V to +13V; (2)IN_, COM_, NC_, NO_ (Note 1): -0.3V to (V+ + 0.3V); (3)Continuous Current (any terminal): ±10mA; (4)Peak Current, COM_, NO_, NC_ (pulsed at 1ms, 10% duty cycle max): ±20mA; (5)ESD per Method 3015.7 : >2000V; (6)Continuous Power Dissipation SOT23-6 (derate 7.1mW/°C above +70°C): 571mW, SOT23-8 (derate 5.3mW/°C above +70°C): 421mW, QFN (derate 24.4mW/°C above +70°C): 1951mW, μMAX (derate 4.10mW/°C above +70°C): 330mW, Narrow SO (derate 5.88mW/°C above +70°C): 471mW, Plastic DIP (derate 9.09mW/°C above +70°C): 727mW; (7)Operating Temperature Ranges: 0°C to +70°C; (8)Storage Temperature Range : -65°C to +150°C; (9)Lead Temperature (soldering, 10s): +300°C.

Features

max4541csa-t features: (1)Low RON: 60Ω max (33Ω typ); (2)RON Matching Between Channels: 2Ω max; (3)RON Flatness: 6Ω max; (4)Guaranteed Charge Injection: 5pC max; (5)+2.7V to +12V Single-Supply Operation; (6)Low Power Consumption: <5μW; (7)Low Leakage Current Over Temperature: 10nA max at +85°C; (8)Fast Switching: tON = 35ns, tOFF = 25ns; (9)Guaranteed Break-Before-Make; (10)TTL/CMOS-Logic Compatible.
