Product Summary
The M34506M4-501FP is a 4-bit single-chip microcomputer designed with CMOS technology. Its CPU is that of the 4500 series using a simple, high-speed instruction set. The computer is equipped with two 8-bit timers (each timer has a reload register), interrupts, and 10-bit A/D converter. Application is electrical household appliance, consumer electronic products, office automation equipment, etc.
Parametrics
M34506M4-501FP absolute maximum ratings: (1)Supply voltage: –0.3 to 6.5 V; (2)Input voltage P0, P1, P2, D0, D1, D2/C, D3/K, RESET, XIN: –0.3 to VDD+0.3 V; (3)Input voltage AIN0–AIN1: –0.3 to VDD+0.3 V; (4)Output voltage P0, P1, P2, D0, D1, D2/C, D3/K, RESET: –0.3 to VDD+0.3 V; (5)Output voltage XOUT: –0.3 to VDD+0.3 V; (6)Power dissipation: 300 mW; (7)Operating temperature range: –20 to 85 ℃; (8)Storage temperature range: –40 to 125 ℃.
Features
M34506M4-501FP features: (1)Minimum instruction execution time: 0.68 μs (at 4.4 MHz oscillation frequency, in high-speed mode); (2)Supply voltage: 2.0 V to 5.5 V (It depends on the oscillation frequency and operating mode.); (3)Timer 1: 8-bit timer with a reload register; (4)Timer 2: 8-bit timer with a reload register; (5)Interrupt: 4 sources; (6)Key-on wakeup function pins: 12; (7)Input/Output port: 14; (8)A/D converter: 10-bit successive comparison method; (9)Watchdog timer; (10)Clock generating circuit (ceramic resonator/RC oscillation); (11)LED drive directly enabled (port D).
Diagrams
