LT1316CMS8#TR

LT1316CMS8#TR, DC/DC converter, 1.5 V, 500 mA, 12 V, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.44~2.44 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1390 :	2.44 / Piece

PartNumber:: LT1316CMS8#TR

Brand:: LT Electronics Co., Ltd. - LT | Pack: SOP | D/C: 01+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-10

From Other Seller

Part Number:LT1316CMS8#TR
US $2.44 - 2.44
Quantity:

piece

Product Summary

The LT1316CMS8#TR is a micropower step-up DC/DC converter that operates from an input voltage as low as 1.5V. A programmable input current limiting function allows precise control of peak switch current. Peak switch current can be set to any value between 30mA and 500mA by adjusting one resistor. This is particularly useful for DC/DC converters operating from high source impedance inputs such as lithium coin cells or telephone lines. Applications are (1)Battery Backup; (2)LCD Bias; (3)Low Power – 48V to 5V/3.3V Converters.

Parametrics

LT1316CMS8#TR absolute maximum ratings: (1)VIN Voltage: 12V; (2)SW Voltage: –0.4V to 30V; (3)FB Voltage: VIN + 0.3V; (4)RSET Voltage: 5V; (5)SHDN Voltage: 6V; (6)LBI Voltage: VIN; (7)LBO Voltage: 12V; (8)Maximum Switch Current: 750mA; (9)Maximum Junction Temperature: 125°C; (10)Operating Temperature Range Commercial: 0°C to 70°C; (11)Operating Temperature Range Extended Commercial (Note 1): –40°C to 85°C; (12)Operating Temperature Range Industrial (Note 2): –40°C to 85°C; (13)Storage Temperature Range: – 65°C to 150°C; (14)Lead Temperature (Soldering, 10 sec: 300°C.

Features

LT1316CMS8#TR features: (1)Precise Control of Peak Switch Current; (2)Quiescent Current: 33mA iActive Mode; 3mA iShutdowMode; (3)Low-Battery Detector Active iShutdown; (4)Low Switch VCESAT: 300mV at 500mA; (5)8-Lead MSOP and SO Packages; (6)Operates with VIN as Low as 1.5V; (7)Logic Level ShutdowPin.
