LP2951CMMX-3.3

LP2951CMMX-3.3, micropower voltage regulator, 40 mV, 100 mA, 75 μA, 30 V, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.65~1.65 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 3500 :	1.65 / Piece

PartNumber:: LP2951CMMX-3.3

Brand:: National Semiconductor - NS | Pack: SOP | D/C: 99+

Availability:: Supply Ability: 100/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-10

From Other Seller

Part Number:LP2951CMMX-3.3
US $1.65 - 1.65
Quantity:

piece

Product Summary

The LP2951CMMX-3.3 is a micropower voltage regulator with very low quiescent current (75μA typ.) and very low dropout voltage (typ. 40mV at light loads and 380mV at 100mA). The LP2951CMMX-3.3 is ideally suited for use in battery-powered system. Furthermore, the quiescent current of the LP2951CMMX-3.3 increases only slightly in dropout, prolonging battery life.

Parametrics

LP2951CMMX-3.3 absolute maximum ratings: (1)Input Supply Voltage: -0.3 to +30V; (2)SHUTDOWN Input Voltage, Error Comparator Output Voltage, (Note 9)FEEDBACK Input Voltage (Note 9)(Note 10): -1.5 to +30V; (3)Power Dissipation: Internally Limited; (4)Junction Temperature (TJ): +150°C; (5)Ambient Storage Temperature: -65° to +150°C; (6)Soldering Dwell Time, Temperature Wave: 4 seconds, 260°C; (7)Soldering Dwell Time, Temperature Infrared: 10 seconds, 240°C; (8)Soldering Dwell Time, Temperature Vapor Phase: 75 seconds, 219°C; (9)ESD Rating Human Body Model(Note 18): 2500V; (10)Maximum Input Supply Voltage: 30V; (11)Junction Temperature Range (TJ)(Note 8)LP2951: -55°C to +150°C.

Features

LP2951CMMX-3.3 features: (1)5V, 3V, and 3.3V versions available; (2)High accuracy output voltage; (3)Guaranteed 100mA output current; (4)Extremely low quiescent current; (5)Low dropout voltage; (6)Extremely tight load and line regulation; (7)Very low temperature coefficient; (8)Use as Regulator or Reference; (9)Needs minimum capacitance for stability; (10)Current and Thermal Limiting; (11)Stable with low-ESR output capacitors (10mΩ to 6Ω).
