LM2903MX

LM2903MX, Low Power Low Offset Voltage Dual Comparator, SO-8, 36V, 50mA, National Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.26~0.26 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2000 :	0.26 / Piece

PartNumber:: LM2903MX

Brand:: National Semiconductor - NS | Pack: | D/C: 10+

Availability:: Supply Ability: 2000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-09-10

From Other Seller

Part Number:LM2903MX
US $0.26 - 0.26
Quantity:

piece

Product Summary

The LM2903MX is a Low Power Low Offset Voltage Dual Comparator. The LM2903MX consists of two independent precision voltage comparators with an offset voltage specification aslow as 2.0 mV max for two comparators which were de-signed specifically to operate from a single power supplyover a wide range of voltages. Operation from split powersupplies is also possible and the low power supply current drain is independent of the magnitude of the power supplyvoltage. The comparator also has a unique characteris-tic in that the input common-mode voltage range includesground, even though operated from a single power supply voltage. The applications of the LM2903MX include High precision comparators, Reduced VOS drift over temperature, Eliminates need for dual supplies, Allows sensing near ground, Compatible with all forms of logic, Power drain suitable for battery operation.

Parametrics

LM2903MX absolute maximum ratings: (1)Supply Voltage: +36V; (2)Differential Input Voltage: 36V; (3)Input Voltage: -0.3V to +36V; (4)Input Current (VIN<-0.3V): 50 mA; (5)Output Short-Circuit to Ground: Continuous; (6)Storage Temperature Range: -65℃ to +150℃; (7)Lead Temperature(Soldering, 10 seconds): +260℃.

Features

LM2903MX features: (1)Wide supply: Voltage range: 2.0V to 36V; Single or dual supplies: ±1.0V to ±18V; (2)Very low supply current drain (0.4 mA)-independent of supply voltage; (3)Low input biasing current: 25 nA; (4)Low input offset current: ±5nA; (5)Maximum offset voltage: ±3mV; (6)Input common-mode voltage range includes ground; (7)Differential input voltage range equal to the power supply voltage; (8)Low output saturation voltage: 250 mV at 4 mA; (9)Output voltage compatible with TTL, DTL, ECL, MOSand CMOS logic systems; (10)Available in the 8-Bump (12 mil) micro SMD package; (11)See AN-1112 for micro SMD considerations.
