The HIN232CPZ is a +5V powered RS-232 transmitter/receiver interface circuit. It meets all ElA high-speed RS-232E and V.28 specifications, and is particularly suited for those applications where ±12V is not available. The HIN232CPZ requires a single +5V power supply and feature onboard charge pump voltage converters which generate +10V and -10V supplies from the 5V supply. The applications of the HIN232CPZ include Any System Requiring RS-232 Communication Ports: Computer - Portable, Mainframe, Laptop; Peripheral - Printers and Terminals; Instrumentation; Modems.

Parametrics

HIN232CPZ absolute maximum ratings: (1)VCC to Ground: (GND -0.3V) <VCC < 6V; (2)V+ to Ground:(VCC -0.3V) <V+ < 12V; (3)V- to Ground: -12V < V- < (GND +0.3V); (4)Input Voltages: TIN: -0.3V < VIN < (V+ +0.3V), RIN: ±30V; (5)Output Voltages: TOUT: (V- -0.3V) < VTXOUT < (V+ +0.3V), ROUT: (GND -0.3V) < VRXOUT < (V+ +0.3V); (6)Short Circuit Duration: TOUT: Continuous, ROUT: Continuous.

Features

HIN232CPZ features: (1)Meets All RS-232E and V.28 Specifications; (2)Requires Only Single +5V Power Supply - (+5V and +12V - HIN239); (3)High Data Rate: 120kbps; (4)Onboard Voltage Doubler/Inverter; (5)Low Power Consumption; (6)Low Power Shutdown Function; (7)Three-State TTL/CMOS Receiver Outputs; (8)Multiple Drivers: ±10V Output Swing for 5V input; 300Ω Power-Off Source Impedance; Output Current Limiting; TTL/CMOS Compatible; 30V/μs Maximum Slew Rate; (9)Multiple Receivers: ±30V Input Voltage Range; 3kΩ to 7kΩ Input Impedance; 0.5V Hysteresis to Improve Noise Rejection; (10)Pb-free Available (RoHS compliant).
