Product Summary

The MIC2026-2YM is a high-side MOSFET switch optimized for general-purpose power distribution requiring circuit protection. The MIC2026-2YM is internally current limited and have thermal shutdown that protects the device and load. The MIC2026-2YM offers “smart” thermal shutdown that reduces current consumption in fault modes. When a thermal shutdown fault occurs, the output is latched off until the faulty load is removed. Removing the load or toggling the enable input will reset the device output. Both devices employ soft-start circuitry that minimizes inrush current in applications where highly capacitive loads are employed.

Parametrics

MIC2026-2YM absolute maximum ratings: (1)Supply Voltage (VBINB): –0.3V to +6V; (2)Fault Flag Voltage(VBFLGB): +6V; (3)Fault Flag Current (IBFLGB): 25mA; (4)Output Voltage (VBOUTB): +6V; (5)Output Current (IBOUTB): Internally Limited; (6)Enable Input (IBENB): –0.3V to VIN + 3V; (7)Storage Temperature (TBSB): –65℃ to +150 ℃.

Features

MIC2026-2YM features: (1)140Ω maximum on-resistance per channel; (2)2.7V to 5.5V operating range; (3)500mA minimum continuous current per channel; (4)Shortcircuit protection with thermal shutdown; (5)Thermally isolated channels; (6)Fault status flag with 3ms filter eliminates false; (7)assertions; (8)Undervoltage lockout; (9)Reverse current flow blocking; (10)Circuit breaker mode; (11)Logic-compatible inputs; (12)Soft-start circuit; (13)Low quiescent current.

Diagrams

MIC2026-2YM pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MIC2026-2YM
MIC2026-2YM


IC DISTRIBUTION SW DUAL 8-SOIC

Data Sheet

0-1: $0.68
1-25: $0.57
25-100: $0.46
100-250: $0.34
250-500: $0.32
MIC2026-2YM TR
MIC2026-2YM TR


IC SW DISTRIBUTION 2CHAN 8SOIC

Data Sheet

0-1: $0.68
1-25: $0.57
25-100: $0.46
100-250: $0.34
250-500: $0.32
