GTL2005PW

gtl2005pw, Quad GTL/GTL, 4.6 V, 50 mA, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.28~0.28 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 900 :	0.28 / Piece

PartNumber:: GTL2005PW

Brand:: NXP Semiconductors - nxp | Pack: | D/C: 10+

Availability:: Supply Ability: 900/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-09-11

From Other Seller

Part Number:GTL2005PW
US $0.28 - 0.28
Quantity:

piece

Product Summary

The gtl2005pw is a Quad GTL/GTL to LVTTL/TTL bidirectional non-latched translator.

Parametrics

gtl2005pw absolute maximum ratings: (1)VCC DC supply voltage: –0.5 to +4.6 V; (2)IIK DC input diode current VI < 0: –50 mA; (3)VI DC input voltage A port: –0.5 to +7.0 V; (4)VI DC input voltage B port: –0.5 to +4.6 V; (5)IOK DC output diode current VO < 0: –50 mA; (6)VO DC output voltage Output in Off or High state; A port: –0.5 to +7.0 V; (7)VO DC output voltage Output in Off or High state; B port: –0.5 to +4.6 V; (8)IOL Current into any output in the LOW state A port: 128 mA; (9)IOL Current into any output in the LOW state B port: 80 mA; (10)IOH Current into any output in the HIGH state A port: –64 mA; (11)Tstg Storage temperature range: –60℃ to +150℃.

Features

gtl2005pw features: (1)Operates as a quad GTL/GTL+ sampling receiver or as a LVTTL/TTL to GTL/GTL+ driver; (2)Quad bidirectional bus interface; (3)Live insertion/extraction permitted; (4)Latch-up protection exceeds 500 mA per JESD78; (5)ESD protection exceeds 2000 V HBM per JESD22-A114, and 1000 V CDM per JESD22-CC101.
